SMD -modules

The Superior Modular Dock (SMD) system is crafted using advanced rotational moulding techniques with High-Quality Polyethylene, ensuring the creation of durable, flexible, and UV-Stabilized modular components. Designed specifically for demanding marine environments, these modules are engineered to resist deterioration, even in harsh conditions. Their robust construction makes them highly resistant to impact and wear, making the SMD system an ideal choice for a wide range of public and commercial applications.

The Superior Modular Dock (SMD) System is made from rotomoulded polyethylene modules that are durable, UV sterilized, tough, and slip-resistant. They can be configured into a variety of shapes and applications. It is the main building block of Superior Jetties Floating Platform Systems.

These are available in a wide range of sizes – allowing for multiple layouts. These are easily mountable and moveable

IDEAL APPLICATION

- MARINAS
- HELIPADS
- FLOATING PLATFORMS
- SWIMMING PLATFORMS
- SETTLEMENT PONDS
- AQUACULTURE
- RAMPS FOR BOAT LAUNCHING
  AND RETRIEVAL

Technical Details:-

Size:-
- 3Mtr Long x 2Mtr Wide x 0.4Mtr Height (6 Sq.M)
- 3Mtr Long x 1.5Mtr Wide x 0.4Mtr Height (4.5 Sq.M)
Color :- Grey
Deck :- CSIRO slip resistant certified, raised tile pattern, self-draining.
Resistance to Degradation :- Extremely High
Resistance to Impact :- Extremely High
Loading Capacity:-
- One SMD (6SQM) can take 2.4 Ton at full submersion in water.
- One SMD(4.5SQM) can take 1.6Ton at full submersion in water
The module is specified to Australian Standard enforced by Superior Jetties- Australia.

These dimensions are given for broad reference. Please keep a tolerance of +/- 2% in all dimensions.

TECHNICAL SPECIFICATION

Size	Length	Width	Height
1	3.0 m	2.0 m	0.4 m
2	3.0 m	1.5 m	0.4 m
3	2.0 m	2.0 m	0.4 m
4	2.0 m	1.5 m	0.4 m
5	2.0 m	1.0 m	0.4 m
6	1.5 m	1.0 m	0.4 m

Features / Benefits:-

High Durability and Flexibility , No Reduction in Strength after prolonged use
anti-slip Surface
High Quality UV Stable Polyethylene
Easy Cleaning and Maintenance
Easily Mountable and Movable
100 % Recyclable
Container friendly for worldwide shipping
Single Piece Rotational Moulded Modules

Mini Dock

One Mini SMD(0.25 SQM) can take 100 kg at full submersion in water
The module is specified to the Australian Standard enforced by Superior Jetties- Australia.
